PORTABLE/MANPACK H/V/UHF RADIO INTERCEPTION & DF STATION
PORTABLE/MANPACK H/V/UHF RADIO MONITORING & DF STATION
Stratign offers the most advanced solutions for Portable and Manpack H/V/UHF interception and Direction Finding and automated analysis.
These are smaller and light weight systems which are carried in a backpack by the operator and can be used to monitor and locate transmissions while on the move or at halts. They can carry out operations of search, detection, measurement of parameters, direction finding, recording, technical analysis and classification.
The H/V/UHF Monitoring and DF System can be used in various scenarios depending up on the mission requirement. The man-portable or manpack systems are carried on the backpack of a soldier or are transported in smaller man-portable sections. The man-portable ones are taken to the intended locations and deployed for shorter durations of operations, and it helps in carrying out monitoring and DF of the radio transmissions in that area. These portable stations can also work in tandem with our Static or Mobile solutions.
Stratign also offers a fully Automated Spectrum Monitoring System (ASMS) which allows for networking of all Monitoring and DF Stations and are centrally tasked and controlled from a Control Station. This helps in carrying out radio spectrum analysis over a complete Zone or even the Country.
The operation of the system does not require deep knowledge of the radio communication and provides an excellent platform to intelligence agencies for obtaining valuable data intelligence from radio networks which are used by criminals and terrorists.
System Features
Panoramic Spectrum Analysis
Panoramic spectrum analysis within the entire operating frequency range (0.009 – 8000 MHz) or within separate intervals in complicated electromagnetic environment.
Automatic Direction Finding
Automatic direction finding of radio emission sources with random modulation types and spectrum width in single-channel and multi-channel modes.
Frequency – Time Diagram
Plotting frequency-time diagram within analysed frequency ranges.
Measurements
Measuring of electromagnetic field strength and signal parameters.
Demodulation & Decoding
Demodulation of AM, SSB, FM signals and Decoding of TETRA, DMR, DPR, DpMR, NXDN P25, etc. signals.
Bearing Panorama
Building of bearing panorama within operating frequency range.
Real-time Display
Real-time display of bearings, spectrum panorama, bearing history and signal amplitude history.
Technical Analysis
Technical analysis, including revealing of central frequency, signal type, modulation type, signal bandwidth.
Postprocessing Mode
Accumulation of data for further analysis in the postprocessing mode.
Selective DF
Selective direction finding of signals of GSM, UMTS, LTE base stations.
Frequency Hopping Signals
Detection and direction finding of frequency hopping signals (up to 1500 hops per sec).
Display of Bearings
Displaying bearing to a radio emission source in electronic map.
Integrated Electronic Map
Mapping DB information on the electronic map.
Remote Operation
Remote control based on TCP/IP via wire and wireless communication channels.
Frequency/Time Parameters
Check of frequency/time parameters and service information of base station of modern communication and data transmission systems (GSM, IS-95, cdma2000, EV-DO, UMTS, TETRA, DECT, LTE, DMR, APCO P25, dPMR, NXDN).
System Synchronization with GPS/GLONASS Signals
Synchronize system stations based on GLONASS/GPS signals while working in integrated mode for synchronous DF and LF of radio signal sources.
Triangulation
Transmitter location evaluation based on direction finding data (triangulation).
TDOA Capability
Transmitter location evaluation based on TDOA method.
