VTOL UNMANNED SYSTEM
VTOL UAV
Stratign’s VTOL unmanned aerial vehicles are mainly designed for security and surveillance applications and have best in class endurance.
Stratign supplies World’s leading unmanned aircrafts designed specifically for demanding security and surveillance applications. What makes our aircraft unique is the ability to take-off and land vertically almost anywhere with the longest flight endurance in the industry, achieved by designing and building the most advanced, lightweight and reliable airframe, propulsion and avionics systems available, matched with day and night vision payloads and long-range
data links. Designed specifically for security and surveillance type applications, our aircraft are ideally suited for long range missions, border patrol, search and rescue, asset monitoring, conservation and other similar applications. Two options of the system are: 2m Wingspan UAV and 3m Wingspan.
System Features
Airframe
One of the most advanced lightweight and highest performing airframes made from aerospace grade carbon fibre. The airframe can be assembled in under 60 seconds with no tools required and includes a high quality flight case.
VTOL Propulsion
100% reliability status with not a single mid-flight failure of the vertical propulsion system on any aircraft to date. It allows for vertical take-off and landing anywhere and acts as backup system in case of main engine cut-out, stalling, over banking, etc.
Combustion
It has the ability to fly longer and further than any competing product on the market till today. By using fuel powered combustion engines for fixed wing propulsion with an advanced electronic fuel injection system, we enable our clients to capture more data and cover much larger areas with flight endurances of up to 12 hours.
Payloads
The aircraft includes advanced dual sensor stabilized day and night EO/IR payloads with object tracking, Geo-lock, GPS and other advanced features, allowing the operators to lock-on to targets, capture and stream real-time HD video to the Command and Control station, control rooms and also across networks and the internet.
Avionics
An exceptionally reliable avionics and autopilot for fixed wing VTOL unmanned aircraft. A small all-in-one unit with integrated multi-redundant power supply and distribution, long range control link, active cooling, navigation light system, ignition system, auxiliary power outputs, multiple I/O and much more. Fly with confidence, from fully autonomous one-click missions, including take-off and landings, advanced guided flight to waypoint missions, allowing you to focus on capturing the data you need safely.
Command and Control
Command and Control is rugged, compact, portable and powerful. The user-friendly interface enables quick and easy mission planning and flight control. Switch seamlessly between flight modes and payload settings while ensuring real-time data and video communication. Dual HD displays, long range antenna tracking options, custom integration capabilities and more allow for reliable communication and control of both aircraft and payload.
Stratign supplies World’s leading unmanned aircrafts designed specifically for demanding security and surveillance applications. What makes our aircraft unique is the ability to take-off and land vertically almost anywhere with the longest flight endurance in the industry, achieved by designing and building the most advanced, lightweight and reliable airframe, propulsion and avionics systems available, matched with day and night vision payloads and long-range data links. Designed specifically for security and surveillance type applications, our aircraft are ideally suited for long range missions, border patrol, search and rescue, asset monitoring, conservation and other similar applications. Two options of the system are: 2m Wingspan UAV and 3m Wingspan.
System Features
Airframe
One of the most advanced lightweight and highest performing airframes made from aerospace grade carbon fibre. The airframe can be assembled in under 60 seconds with no tools required and includes a high quality flight case.
VTOL Propulsion
100% reliability status with not a single mid-flight failure of the vertical propulsion system on any aircraft to date. It allows for vertical take-off and landing anywhere and acts as backup system in case of main engine cut-out, stalling, over banking, etc.
Combustion
It has the ability to fly longer and further than any competing product on the market till today. By using fuel powered combustion engines for fixed wing propulsion with an advanced electronic fuel injection system, we enable our clients to capture more data and cover much larger areas with flight endurances of up to 12 hours.
Payloads
The aircraft includes advanced dual sensor stabilized day and night EO/IR payloads with object tracking, Geo-lock, GPS and other advanced features, allowing the operators to lock-on to targets, capture and stream real-time HD video to the Command and Control station, control rooms and also across networks and the internet.
Avionics
An exceptionally reliable avionics and autopilot for fixed wing VTOL unmanned aircraft. A small all-in-one unit with integrated multi-redundant power supply and distribution, long range control link, active cooling, navigation light system, ignition system, auxiliary power outputs, multiple I/O and much more. Fly with confidence, from fully autonomous one-click missions, including take-off and landings, advanced guided flight to waypoint missions, allowing you to focus on capturing the data you need safely.
Command and Control
Command and Control is rugged, compact, portable and powerful. The user-friendly interface enables quick and easy mission planning and flight control. Switch seamlessly between flight modes and payload settings while ensuring real-time data and video communication. Dual HD displays, long range antenna tracking options, custom integration capabilities and more allow for reliable communication and control of both aircraft and payload.
Specification
Specification
| PARAMETER | 2m WINGSPAN | 3m WINGSPAN |
|---|---|---|
| Wingspan | 2000 mm | 3000 mm |
| Length | 1562 mm | 2300 mm |
| Height (Wing Tips) | 378 mm | 525 mm |
| Ground Clearance (Fuselage) | 126 mm | 170 mm |
| Ground Clearance (Pusher Prop) | 25 mm | 65 mm |
| MTOW (Maximum Take-off Weight) | <10 Kg | <18 Kg |
| Empty Airframe | <3 Kg | <5.8 Kg |
| RTF (Dry Weight) | <6.75 Kg | <11.8 Kg |
| RTF (Including Fuel and Batteries) | <9.4 Kg | <16.1 Kg |
| Max Payload | <600 gm | <1.5 Kg |
| Endurance | 4-6 hours | 8-12 hours |
| Cruise Speed | 22 m/s | 21 m/s |
| VNE (Velocity Never Exceed) | 30 m/s | 30 m/s |
| Maximum Crosswind | 10-15 m/s | 10-15 m/s |
| Service Ceiling | 10,000 ft AMSL | 13,000 ft AMSL |
| Temperature Range | -10° C to +50° C | -10° C to +50° C |
| PARAMETER | 2m WINGSPAN |
|---|---|
| Wingspan | 2000 mm |
| Length | 1562 mm |
| Height (Wing Tips) | 378 mm |
| Ground Clearance (Fuselage) | 126 mm |
| Ground Clearance (Pusher Prop) | 25 mm |
| MTOW (Maximum Take-off Weight) | <10 Kg |
| Empty Airframe | <3 Kg |
| RTF (Dry Weight) | <6.75 Kg |
| RTF (Including Fuel and Batteries) | <9.4 Kg |
| Max Payload | <600 gm |
| Endurance | 4-6 hours |
| Cruise Speed | 22 m/s |
| VNE (Velocity Never Exceed) | 30 m/s |
| Maximum Crosswind | 10-15 m/s |
| Service Ceiling | 10,000 ft AMSL |
| Temperature Range | -10° C to +50° C |
| PARAMETER | 3m WINGSPAN |
|---|---|
| Wingspan | 3000 mm |
| Length | 2300 mm |
| Height (Wing Tips) | 525 mm |
| Ground Clearance (Fuselage) | 170 mm |
| Ground Clearance (Pusher Prop) | 65 mm |
| MTOW (Maximum Take-off Weight) | <18 Kg |
| Empty Airframe | <5.8 Kg |
| RTF (Dry Weight) | <11.8 Kg |
| RTF (Including Fuel and Batteries) | <16.1 Kg |
| Max Payload | <1.5 Kg |
| Endurance | 8-12 hours |
| Cruise Speed | 21 m/s |
| VNE (Velocity Never Exceed) | 30 m/s |
| Maximum Crosswind | 10-15 m/s |
| Service Ceiling | 13,000 ft AMSL |
| Temperature Range | -10° C to +50° C |
